The BaseVolume class provides common functionality and an interface for other volume classes to implement. More...
#include <BaseVolume.h>
Classes | |
class | Sampler |
Public Types | |
typedef _VoxelType | VoxelType |
Public Member Functions | |
VoxelType | getBorderValue (void) const |
Gets the value used for voxels which are outside the volume. | |
Region | getEnclosingRegion (void) const |
Gets a Region representing the extents of the Volume. | |
int32_t | getWidth (void) const |
Gets the width of the volume in voxels. | |
int32_t | getHeight (void) const |
Gets the height of the volume in voxels. | |
int32_t | getDepth (void) const |
Gets the depth of the volume in voxels. | |
int32_t | getLongestSideLength (void) const |
Gets the length of the longest side in voxels. | |
int32_t | getShortestSideLength (void) const |
Gets the length of the shortest side in voxels. | |
float | getDiagonalLength (void) const |
Gets the length of the diagonal in voxels. | |
VoxelType | getVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos) const |
Gets a voxel at the position given by x,y,z coordinates. | |
VoxelType | getVoxelAt (const Vector3DInt32 &v3dPos) const |
Gets a voxel at the position given by a 3D vector. | |
void | setBorderValue (const VoxelType &tBorder) |
Sets the value used for voxels which are outside the volume. | |
bool | setVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos, VoxelType tValue) |
Sets the voxel at the position given by x,y,z coordinates. | |
bool | setVoxelAt (const Vector3DInt32 &v3dPos, VoxelType tValue) |
Sets the voxel at the position given by a 3D vector. | |
uint32_t | calculateSizeInBytes (void) |
Calculates approximatly how many bytes of memory the volume is currently using. |
Protected Member Functions | |
BaseVolume (const Region ®Valid) | |
Constructor for creating a fixed size volume. | |
BaseVolume (const BaseVolume &rhs) | |
Copy constructor. | |
~BaseVolume () | |
Destructor. | |
BaseVolume & | operator= (const BaseVolume &rhs) |
Assignment operator. |
Protected Attributes | |
Region | m_regValidRegion |
int32_t | m_uLongestSideLength |
int32_t | m_uShortestSideLength |
float | m_fDiagonalLength |
The BaseVolume class provides common functionality and an interface for other volume classes to implement.
You should not try to create an instance of this class directly. Instead you should use RawVolume, SimpleVolume, or LargeVolume.
More details to come...
Definition at line 42 of file BaseVolume.h.
typedef _VoxelType PolyVox::BaseVolume< _VoxelType >::VoxelType |
Definition at line 45 of file BaseVolume.h.
|
protected |
Constructor for creating a fixed size volume.
This is protected because you should never create a BaseVolume directly, you should instead use one of the derived classes.
Definition at line 32 of file BaseVolume.inl.
|
protected |
Copy constructor.
This function should never be called.
Copying volumes by value would be expensive, and we want to prevent users from doing it by accident (such as when passing them as paramenters to functions). That said, there are times when you really do want to make a copy of a volume and in this case you should look at the Volumeresampler.
Definition at line 45 of file BaseVolume.inl.
|
protected |
uint32_t PolyVox::BaseVolume< VoxelType >::calculateSizeInBytes | ( | void | ) |
Calculates approximatly how many bytes of memory the volume is currently using.
Note: This function needs reviewing for accuracy...
Reimplemented in PolyVox::LargeVolume< VoxelType >, PolyVox::LargeVolume< int32_t >, PolyVox::SimpleVolume< VoxelType >, and PolyVox::RawVolume< VoxelType >.
Definition at line 219 of file BaseVolume.inl.
VoxelType PolyVox::BaseVolume< VoxelType >::getBorderValue | ( | void | ) | const |
Gets the value used for voxels which are outside the volume.
The border value is returned whenever an attempt is made to read a voxel which is outside the extents of the volume.
Reimplemented in PolyVox::LargeVolume< VoxelType >, PolyVox::LargeVolume< int32_t >, PolyVox::SimpleVolume< VoxelType >, and PolyVox::RawVolume< VoxelType >.
Definition at line 77 of file BaseVolume.inl.
int32_t PolyVox::BaseVolume< VoxelType >::getDepth | ( | void | ) | const |
Gets the depth of the volume in voxels.
Definition at line 117 of file BaseVolume.inl.
float PolyVox::BaseVolume< VoxelType >::getDiagonalLength | ( | void | ) | const |
Gets the length of the diagonal in voxels.
Definition at line 151 of file BaseVolume.inl.
Region PolyVox::BaseVolume< VoxelType >::getEnclosingRegion | ( | void | ) | const |
Gets a Region representing the extents of the Volume.
Definition at line 87 of file BaseVolume.inl.
Referenced by PolyVox::RawVolume< VoxelType >::Sampler::moveNegativeX(), and PolyVox::RawVolume< VoxelType >::Sampler::movePositiveX().
int32_t PolyVox::BaseVolume< VoxelType >::getHeight | ( | void | ) | const |
Gets the height of the volume in voxels.
Definition at line 107 of file BaseVolume.inl.
int32_t PolyVox::BaseVolume< VoxelType >::getLongestSideLength | ( | void | ) | const |
Gets the length of the longest side in voxels.
Definition at line 139 of file BaseVolume.inl.
int32_t PolyVox::BaseVolume< VoxelType >::getShortestSideLength | ( | void | ) | const |
Gets the length of the shortest side in voxels.
Definition at line 128 of file BaseVolume.inl.
VoxelType PolyVox::BaseVolume< VoxelType >::getVoxelAt | ( | int32_t | uXPos, |
int32_t | uYPos, | ||
int32_t | uZPos | ||
) | const |
Gets a voxel at the position given by x,y,z
coordinates.
uXPos | The x position of the voxel |
uYPos | The y position of the voxel |
uZPos | The z position of the voxel |
Reimplemented in PolyVox::LargeVolume< VoxelType >, PolyVox::LargeVolume< int32_t >, PolyVox::SimpleVolume< VoxelType >, and PolyVox::RawVolume< VoxelType >.
Definition at line 163 of file BaseVolume.inl.
Referenced by PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::getVoxel(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px0py0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px0py1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px0py1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px1ny0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px1ny1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px1ny1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px1py0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px1py1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel0px1py1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx0py0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx0py1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx0py1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx1ny0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx1ny1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx1ny1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx1py0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx1py1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1nx1py1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px0py0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px0py1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px0py1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px1ny0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px1ny1nz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px1ny1pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px1py0pz(), PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px1py1nz(), and PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::peekVoxel1px1py1pz().
VoxelType PolyVox::BaseVolume< VoxelType >::getVoxelAt | ( | const Vector3DInt32 & | v3dPos | ) | const |
Gets a voxel at the position given by a 3D vector.
v3dPos | The 3D position of the voxel |
Reimplemented in PolyVox::LargeVolume< VoxelType >, PolyVox::LargeVolume< int32_t >, PolyVox::SimpleVolume< VoxelType >, and PolyVox::RawVolume< VoxelType >.
Definition at line 174 of file BaseVolume.inl.
int32_t PolyVox::BaseVolume< VoxelType >::getWidth | ( | void | ) | const |
Gets the width of the volume in voxels.
Definition at line 97 of file BaseVolume.inl.
Referenced by PolyVox::RawVolume< VoxelType >::Sampler::moveNegativeY(), PolyVox::RawVolume< VoxelType >::Sampler::moveNegativeZ(), PolyVox::RawVolume< VoxelType >::Sampler::movePositiveY(), and PolyVox::RawVolume< VoxelType >::Sampler::movePositiveZ().
|
protected |
Assignment operator.
This function should never be called.
Copying volumes by value would be expensive, and we want to prevent users from doing it by accident (such as when passing them as paramenters to functions). That said, there are times when you really do want to make a copy of a volume and in this case you should look at the Volumeresampler.
Definition at line 66 of file BaseVolume.inl.
void PolyVox::BaseVolume< VoxelType >::setBorderValue | ( | const VoxelType & | tBorder | ) |
Sets the value used for voxels which are outside the volume.
tBorder | The value to use for voxels outside the volume. |
Reimplemented in PolyVox::LargeVolume< VoxelType >, PolyVox::LargeVolume< int32_t >, PolyVox::SimpleVolume< VoxelType >, and PolyVox::RawVolume< VoxelType >.
Definition at line 184 of file BaseVolume.inl.
bool PolyVox::BaseVolume< VoxelType >::setVoxelAt | ( | int32_t | uXPos, |
int32_t | uYPos, | ||
int32_t | uZPos, | ||
VoxelType | tValue | ||
) |
Sets the voxel at the position given by x,y,z
coordinates.
uXPos | the x position of the voxel |
uYPos | the y position of the voxel |
uZPos | the z position of the voxel |
tValue | the value to which the voxel will be set |
Reimplemented in PolyVox::LargeVolume< VoxelType >, PolyVox::LargeVolume< int32_t >, PolyVox::SimpleVolume< VoxelType >, and PolyVox::RawVolume< VoxelType >.
Definition at line 197 of file BaseVolume.inl.
Referenced by PolyVox::BaseVolume< _VoxelType >::Sampler< DerivedVolumeType >::setVoxel().
bool PolyVox::BaseVolume< VoxelType >::setVoxelAt | ( | const Vector3DInt32 & | v3dPos, |
VoxelType | tValue | ||
) |
Sets the voxel at the position given by a 3D vector.
v3dPos | the 3D position of the voxel |
tValue | the value to which the voxel will be set |
Reimplemented in PolyVox::LargeVolume< VoxelType >, PolyVox::LargeVolume< int32_t >, PolyVox::SimpleVolume< VoxelType >, and PolyVox::RawVolume< VoxelType >.
Definition at line 209 of file BaseVolume.inl.
|
protected |
Definition at line 161 of file BaseVolume.h.
|
protected |
Definition at line 156 of file BaseVolume.h.
|
protected |
Definition at line 159 of file BaseVolume.h.
|
protected |
Definition at line 160 of file BaseVolume.h.
