PolyVox
0.2.1
Open source voxel management library
|
#include <RawVolume.h>
Classes | |
class | Sampler |
Public Member Functions | |
RawVolume (const Region ®Valid) | |
Constructor for creating a fixed size volume. | |
~RawVolume () | |
Destructor. | |
VoxelType | getBorderValue (void) const |
Gets the value used for voxels which are outside the volume. | |
VoxelType | getVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos) const |
Gets a voxel at the position given by x,y,z coordinates. | |
VoxelType | getVoxelAt (const Vector3DInt32 &v3dPos) const |
Gets a voxel at the position given by a 3D vector. | |
void | setBorderValue (const VoxelType &tBorder) |
Sets the value used for voxels which are outside the volume. | |
bool | setVoxelAt (int32_t uXPos, int32_t uYPos, int32_t uZPos, VoxelType tValue) |
Sets the voxel at the position given by x,y,z coordinates. | |
bool | setVoxelAt (const Vector3DInt32 &v3dPos, VoxelType tValue) |
Sets the voxel at the position given by a 3D vector. | |
uint32_t | calculateSizeInBytes (void) |
Calculates approximatly how many bytes of memory the volume is currently using. | |
Public Member Functions inherited from PolyVox::BaseVolume< VoxelType > | |
Region | getEnclosingRegion (void) const |
Gets a Region representing the extents of the Volume. | |
int32_t | getWidth (void) const |
Gets the width of the volume in voxels. | |
int32_t | getHeight (void) const |
Gets the height of the volume in voxels. | |
int32_t | getDepth (void) const |
Gets the depth of the volume in voxels. | |
int32_t | getLongestSideLength (void) const |
Gets the length of the longest side in voxels. | |
int32_t | getShortestSideLength (void) const |
Gets the length of the shortest side in voxels. | |
float | getDiagonalLength (void) const |
Gets the length of the diagonal in voxels. |
Protected Member Functions | |
RawVolume (const RawVolume &rhs) | |
Copy constructor. | |
RawVolume & | operator= (const RawVolume &rhs) |
Assignment operator. | |
Protected Member Functions inherited from PolyVox::BaseVolume< VoxelType > | |
BaseVolume (const Region ®Valid) | |
Constructor for creating a fixed size volume. | |
BaseVolume (const BaseVolume &rhs) | |
Copy constructor. | |
~BaseVolume () | |
Destructor. | |
BaseVolume & | operator= (const BaseVolume &rhs) |
Assignment operator. |
Additional Inherited Members | |
Public Types inherited from PolyVox::BaseVolume< VoxelType > | |
typedef VoxelType | VoxelType |
Protected Attributes inherited from PolyVox::BaseVolume< VoxelType > | |
Region | m_regValidRegion |
int32_t | m_uLongestSideLength |
int32_t | m_uShortestSideLength |
float | m_fDiagonalLength |
Definition at line 41 of file RawVolume.h.
PolyVox::RawVolume< VoxelType >::RawVolume | ( | const Region & | regValid | ) |
Constructor for creating a fixed size volume.
This constructor creates a volume with a fixed size which is specified as a parameter.
regValid | Specifies the minimum and maximum valid voxel positions. |
Definition at line 31 of file RawVolume.inl.
PolyVox::RawVolume< VoxelType >::~RawVolume | ( | ) |
|
protected |
Copy constructor.
This function should never be called.
Copying volumes by value would be expensive, and we want to prevent users from doing it by accident (such as when passing them as paramenters to functions). That said, there are times when you really do want to make a copy of a volume and in this case you should look at the Volumeresampler.
Definition at line 48 of file RawVolume.inl.
uint32_t PolyVox::RawVolume< VoxelType >::calculateSizeInBytes | ( | void | ) |
Calculates approximatly how many bytes of memory the volume is currently using.
Note: This function needs reviewing for accuracy...
Reimplemented from PolyVox::BaseVolume< VoxelType >.
Definition at line 205 of file RawVolume.inl.
VoxelType PolyVox::RawVolume< VoxelType >::getBorderValue | ( | void | ) | const |
Gets the value used for voxels which are outside the volume.
The border value is returned whenever an attempt is made to read a voxel which is outside the extents of the volume.
Reimplemented from PolyVox::BaseVolume< VoxelType >.
Definition at line 82 of file RawVolume.inl.
Referenced by PolyVox::RawVolume< VoxelType >::Sampler::getVoxel().
VoxelType PolyVox::RawVolume< VoxelType >::getVoxelAt | ( | int32_t | uXPos, |
int32_t | uYPos, | ||
int32_t | uZPos | ||
) | const |
Gets a voxel at the position given by x,y,z
coordinates.
uXPos | The x position of the voxel |
uYPos | The y position of the voxel |
uZPos | The z position of the voxel |
Reimplemented from PolyVox::BaseVolume< VoxelType >.
Definition at line 94 of file RawVolume.inl.
Referenced by PolyVox::LowPassFilter< SrcVolumeType, DstVolumeType, AccumulationType >::executeSAT(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel0px0py1nz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel0px0py1pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel0px1ny0pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel0px1ny1nz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel0px1ny1pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel0px1py0pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel0px1py1nz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel0px1py1pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1nx0py0pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1nx0py1nz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1nx0py1pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1nx1ny0pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1nx1ny1nz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1nx1ny1pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1nx1py0pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1nx1py1nz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1nx1py1pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1px0py0pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1px0py1nz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1px0py1pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1px1ny0pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1px1ny1nz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1px1ny1pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1px1py0pz(), PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1px1py1nz(), and PolyVox::RawVolume< VoxelType >::Sampler::peekVoxel1px1py1pz().
VoxelType PolyVox::RawVolume< VoxelType >::getVoxelAt | ( | const Vector3DInt32 & | v3dPos | ) | const |
Gets a voxel at the position given by a 3D vector.
v3dPos | The 3D position of the voxel |
Reimplemented from PolyVox::BaseVolume< VoxelType >.
Definition at line 121 of file RawVolume.inl.
|
protected |
Assignment operator.
This function should never be called.
Copying volumes by value would be expensive, and we want to prevent users from doing it by accident (such as when passing them as paramenters to functions). That said, there are times when you really do want to make a copy of a volume and in this case you should look at the Volumeresampler.
Definition at line 71 of file RawVolume.inl.
void PolyVox::RawVolume< VoxelType >::setBorderValue | ( | const VoxelType & | tBorder | ) |
Sets the value used for voxels which are outside the volume.
tBorder | The value to use for voxels outside the volume. |
Reimplemented from PolyVox::BaseVolume< VoxelType >.
Definition at line 130 of file RawVolume.inl.
Referenced by PolyVox::RawVolume< VoxelType >::RawVolume().
bool PolyVox::RawVolume< VoxelType >::setVoxelAt | ( | int32_t | uXPos, |
int32_t | uYPos, | ||
int32_t | uZPos, | ||
VoxelType | tValue | ||
) |
Sets the voxel at the position given by x,y,z
coordinates.
uXPos | the x position of the voxel |
uYPos | the y position of the voxel |
uZPos | the z position of the voxel |
tValue | the value to which the voxel will be set |
Reimplemented from PolyVox::BaseVolume< VoxelType >.
Definition at line 143 of file RawVolume.inl.
Referenced by PolyVox::LowPassFilter< SrcVolumeType, DstVolumeType, AccumulationType >::executeSAT().
bool PolyVox::RawVolume< VoxelType >::setVoxelAt | ( | const Vector3DInt32 & | v3dPos, |
VoxelType | tValue | ||
) |
Sets the voxel at the position given by a 3D vector.
v3dPos | the 3D position of the voxel |
tValue | the value to which the voxel will be set |
Reimplemented from PolyVox::BaseVolume< VoxelType >.
Definition at line 174 of file RawVolume.inl.
