PolyVox::Region Class Reference

#include <Region.h>

Collaboration diagram for PolyVox::Region:

List of all members.

Public Member Functions
	Region ()
	Region (const Vector3DInt32 &v3dLowerCorner, const Vector3DInt32 &v3dUpperCorner)
	Region (int32_t iLowerX, int32_t iLowerY, int32_t iLowerZ, int32_t iUpperX, int32_t iUpperY, int32_t iUpperZ)
bool	operator== (const Region &rhs) const throw ()
	Equality Operator.
bool	operator!= (const Region &rhs) const throw ()
	Inequality Operator.
const Vector3DInt32 &	getLowerCorner (void) const
const Vector3DInt32 &	getUpperCorner (void) const
void	setLowerCorner (const Vector3DInt32 &v3dLowerCorner)
void	setUpperCorner (const Vector3DInt32 &v3dUpperCorner)
bool	containsPoint (const Vector3DFloat &pos, float boundary=0.0f) const
bool	containsPoint (const Vector3DInt32 &pos, uint8_t boundary=0) const
bool	containsPointInX (float pos, float boundary=0.0f) const
bool	containsPointInX (int32_t pos, uint8_t boundary=0) const
bool	containsPointInY (float pos, float boundary=0.0f) const
bool	containsPointInY (int32_t pos, uint8_t boundary=0) const
bool	containsPointInZ (float pos, float boundary=0.0f) const
bool	containsPointInZ (int32_t pos, uint8_t boundary=0) const
void	cropTo (const Region &other)
int32_t	depth (void) const
	Deprecated and misleading.
int32_t	height (void) const
	Deprecated and misleading.
void	shift (const Vector3DInt32 &amount)
void	shiftLowerCorner (const Vector3DInt32 &amount)
void	shiftUpperCorner (const Vector3DInt32 &amount)
Vector3DInt32	dimensions (void)
	Deprecated and misleading.
int32_t	width (void) const
	Deprecated and misleading.
Static Public Attributes
static const Region	MaxRegion

---

Detailed Description

Definition at line 36 of file Region.h.

---

Constructor & Destructor Documentation

PolyVox::Region::Region

(

)

Definition at line 37 of file Region.cpp.

PolyVox::Region::Region	(	const Vector3DInt32 &	v3dLowerCorner,
		const Vector3DInt32 &	v3dUpperCorner
	)

Definition at line 43 of file Region.cpp.

Here is the call graph for this function:

PolyVox::Region::Region	(	int32_t	iLowerX,
		int32_t	iLowerY,
		int32_t	iLowerZ,
		int32_t	iUpperX,
		int32_t	iUpperY,
		int32_t	iUpperZ
	)

Definition at line 53 of file Region.cpp.

Here is the call graph for this function:

---

Member Function Documentation

bool PolyVox::Region::containsPoint	(	const Vector3DFloat &	pos,
		float	boundary = 0.0f
	)			const

Definition at line 105 of file Region.cpp.

Referenced by PolyVox::SimpleVolume< VoxelType >::getVoxelAt(), PolyVox::RawVolume< VoxelType >::getVoxelAt(), PolyVox::LargeVolume< VoxelType >::getVoxelAt(), PolyVox::ConstVolumeProxy< VoxelType >::getVoxelAt(), PolyVox::SimpleVolume< VoxelType >::setVoxelAt(), PolyVox::RawVolume< VoxelType >::setVoxelAt(), PolyVox::LargeVolume< VoxelType >::setVoxelAt(), and PolyVox::ConstVolumeProxy< VoxelType >::setVoxelAt().

Here is the call graph for this function:

bool PolyVox::Region::containsPoint	(	const Vector3DInt32 &	pos,
		uint8_t	boundary = 0
	)			const

Definition at line 115 of file Region.cpp.

Here is the call graph for this function:

bool PolyVox::Region::containsPointInX	(	float	pos,
		float	boundary = 0.0f
	)			const

Definition at line 125 of file Region.cpp.

Here is the call graph for this function:

bool PolyVox::Region::containsPointInX	(	int32_t	pos,
		uint8_t	boundary = 0
	)			const

Definition at line 131 of file Region.cpp.

Here is the call graph for this function:

bool PolyVox::Region::containsPointInY	(	float	pos,
		float	boundary = 0.0f
	)			const

Definition at line 137 of file Region.cpp.

Here is the call graph for this function:

bool PolyVox::Region::containsPointInY	(	int32_t	pos,
		uint8_t	boundary = 0
	)			const

Definition at line 143 of file Region.cpp.

Here is the call graph for this function:

bool PolyVox::Region::containsPointInZ	(	float	pos,
		float	boundary = 0.0f
	)			const

Definition at line 149 of file Region.cpp.

Here is the call graph for this function:

bool PolyVox::Region::containsPointInZ	(	int32_t	pos,
		uint8_t	boundary = 0
	)			const

Definition at line 155 of file Region.cpp.

Here is the call graph for this function:

void PolyVox::Region::cropTo

(

const Region &

other

)

Definition at line 161 of file Region.cpp.

Here is the call graph for this function:

int32_t PolyVox::Region::depth

(

void

)

const

Deprecated and misleading.

Definition at line 171 of file Region.cpp.

Here is the call graph for this function:

Vector3DInt32 PolyVox::Region::dimensions

(

void

)

Deprecated and misleading.

Definition at line 201 of file Region.cpp.

const Vector3DInt32 & PolyVox::Region::getLowerCorner

(

void

)

const

Definition at line 85 of file Region.cpp.

Referenced by PolyVox::AmbientOcclusionCalculator< VolumeType, VoxelType >::AmbientOcclusionCalculator(), PolyVox::VolumeResampler< SrcVolumeType, DestVolumeType, VoxelType >::execute(), PolyVox::SurfaceExtractor< VolumeType, VoxelType >::execute(), PolyVox::LowPassFilter< SrcVolumeType, DestVolumeType, VoxelType >::execute(), PolyVox::CubicSurfaceExtractorWithNormals< VolumeType, VoxelType >::execute(), PolyVox::CubicSurfaceExtractor< VolumeType, VoxelType >::execute(), PolyVox::AmbientOcclusionCalculator< VolumeType, VoxelType >::execute(), PolyVox::LowPassFilter< SrcVolumeType, DestVolumeType, VoxelType >::executeSAT(), PolyVox::LargeVolume< VoxelType >::flush(), PolyVox::BaseVolume< VoxelType >::getDepth(), PolyVox::BaseVolume< VoxelType >::getHeight(), PolyVox::RawVolume< VoxelType >::getVoxelAt(), PolyVox::BaseVolume< VoxelType >::getWidth(), PolyVox::IteratorController< IteratorType >::moveForward(), PolyVox::LargeVolume< VoxelType >::prefetch(), PolyVox::IteratorController< IteratorType >::reset(), PolyVox::SimpleVolume< VoxelType >::resize(), PolyVox::LargeVolume< VoxelType >::resize(), PolyVox::RawVolume< VoxelType >::setVoxelAt(), and PolyVox::VolumeChangeTracker< VoxelType >::unlockRegion().

const Vector3DInt32 & PolyVox::Region::getUpperCorner

(

void

)

const

Definition at line 90 of file Region.cpp.

Referenced by PolyVox::VolumeResampler< SrcVolumeType, DestVolumeType, VoxelType >::execute(), PolyVox::SurfaceExtractor< VolumeType, VoxelType >::execute(), PolyVox::LowPassFilter< SrcVolumeType, DestVolumeType, VoxelType >::execute(), PolyVox::CubicSurfaceExtractorWithNormals< VolumeType, VoxelType >::execute(), PolyVox::CubicSurfaceExtractor< VolumeType, VoxelType >::execute(), PolyVox::AmbientOcclusionCalculator< VolumeType, VoxelType >::execute(), PolyVox::LowPassFilter< SrcVolumeType, DestVolumeType, VoxelType >::executeSAT(), PolyVox::LargeVolume< VoxelType >::flush(), PolyVox::BaseVolume< VoxelType >::getDepth(), PolyVox::BaseVolume< VoxelType >::getHeight(), PolyVox::BaseVolume< VoxelType >::getWidth(), PolyVox::IteratorController< IteratorType >::moveForward(), PolyVox::LargeVolume< VoxelType >::prefetch(), PolyVox::SimpleVolume< VoxelType >::resize(), PolyVox::LargeVolume< VoxelType >::resize(), PolyVox::SurfaceExtractor< VolumeType, VoxelType >::SurfaceExtractor(), and PolyVox::VolumeChangeTracker< VoxelType >::unlockRegion().

int32_t PolyVox::Region::height

(

void

)

const

Deprecated and misleading.

Definition at line 178 of file Region.cpp.

Here is the call graph for this function:

bool PolyVox::Region::operator!=

(

const Region &

rhs

)

const throw ()

Inequality Operator.

Checks whether two Regions are not equal.

Parameters:

rhs

The Region to compare to.

Returns:

true if the Regions do not match.

See also:

operator==

Definition at line 80 of file Region.cpp.

bool PolyVox::Region::operator==

(

const Region &

rhs

)

const throw ()

Equality Operator.

Checks whether two Regions are equal.

Parameters:

rhs

The Region to compare to.

Returns:

true if the Regions match.

See also:

operator!=

Definition at line 69 of file Region.cpp.

void PolyVox::Region::setLowerCorner

(

const Vector3DInt32 &

v3dLowerCorner

)

Definition at line 95 of file Region.cpp.

Referenced by PolyVox::SimpleVolume< VoxelType >::resize(), and PolyVox::LargeVolume< VoxelType >::resize().

void PolyVox::Region::setUpperCorner

(

const Vector3DInt32 &

v3dUpperCorner

)

Definition at line 100 of file Region.cpp.

Referenced by PolyVox::SurfaceExtractor< VolumeType, VoxelType >::execute(), PolyVox::SimpleVolume< VoxelType >::resize(), PolyVox::LargeVolume< VoxelType >::resize(), and PolyVox::SurfaceExtractor< VolumeType, VoxelType >::SurfaceExtractor().

void PolyVox::Region::shift

(

const Vector3DInt32 &

amount

)

Definition at line 185 of file Region.cpp.

Referenced by PolyVox::SurfaceExtractor< VolumeType, VoxelType >::execute().

void PolyVox::Region::shiftLowerCorner

(

const Vector3DInt32 &

amount

)

Definition at line 191 of file Region.cpp.

void PolyVox::Region::shiftUpperCorner

(

const Vector3DInt32 &

amount

)

Definition at line 196 of file Region.cpp.

int32_t PolyVox::Region::width

(

void

)

const

Deprecated and misleading.

Definition at line 208 of file Region.cpp.

Here is the call graph for this function:

---

Member Data Documentation

const Region PolyVox::Region::MaxRegion [static]

Definition at line 41 of file Region.h.

Referenced by PolyVox::LargeVolume< VoxelType >::LargeVolume().

---

The documentation for this class was generated from the following files:

• PolyVoxCore/include/PolyVoxCore/Region.h
• PolyVoxCore/source/Region.cpp
